Power line/ Substations

---

Medium Voltage (MV)

1. MV Cabling – Open trench cable laying is often used a opposed to laying cables directly into cable ducts. This method of laying cables into the ground tends to be used where the cables in use are of a higher voltage (MV HV Cables) and therefore have a greater outside cable diameter.
2. Transformer – A Transformer is a device that transfers electric engery from one alternating -current circuit to one or more other cricuits, either increasing (stepping up) or reducing (stepping down) the voltage.
3. MV Switchgear – In an electric power system, switchgear is composed of electrical disconnect switches, fuse or circuit breakers used to control, protect and isolate electrical equipment. Switchgear is used both to de-engergize equipment to work to be done and to clear faults downstream.

---

Low Voltage (LV)

1. LV Cabling
2. Generator Set
3. Electrical Switchboard
4. Busbar Trunking System
5. Power and Lighting System
6. Lightning Protection & Earthing System

---

Extra Low Voltage (ELV)

1. Telecommunication network
2. SMATV System
3. Network System
4. Structure Cabling
5. Telephone System
6. Closed Circuit Television System (CCTV)
